Renault Magnum 4x2

Model picture

Go to building instructions.

Building instructions

View the full parts list with links to BrickLink making it easy to find retailers selling the parts you need.

Parts list


This model is controlled using LEGO Power Functions.

Difficulty: Hard.

Warning! Fragile model not intended for children's play.

Warning

Fragile

Number of elements: 982.

#pcs

982

Created January 4, 2010.

Last updated November 8, 2010.

Nov

8

2010

Scale: 1:25, Model Team.

Scale

1:25

"Number of wheel sets" x "Driven wheels": 4x2.

Type of Power Functions motor for drive: XL.

Gearing from motor to wheels: 5:7.

Differential type: Standard.

Drive

4x2

Type of steering geometry: Linear.

Type of Power Functions motor used for steering: M.

Steering

Linear

This model has 2 opening doors

Doors

x2

Created by Lasse Deleuran.

Create a BrickLink Parts list (XML format) for import into BrickLink wanted lists.

Go to the YouTube video for this model.

Go to the Brickshelf folder with this model.

Go to the MOCPages page for this model.

Click to download .mpd file to be open with LDraw tools such as MLCad and LDView.

Print building instructions.

About this model

The Magnum is one of the original models of this site and one of the most technically advanced models.

The decoupling mechanism is activated by the steering motor, but might engage prematurely when turning.

The headlights allow up to two sets of Power Functions LED lights.

Note that changing the battery box requires a significant part of the cabin to be disassembled. The truck also has very poor rear wheel grip when a trailer is not attached.



The Power Functions components of this truck are connected as follows


Remote controls

We recommend using the Power Functions remote for controlling this truck.

If the truck is to be driven by people who do not have experience with LEGO Power Functions, then we recommend using our modified remote which blocks the channel selector and uses a long axle as a pointing device.

Building instructions for this LEGO model

The building instructions are made by building the LEGO models in MLCad and generated in LDView using an old version of LPub. All this software is part of LDraw. These web-pages are made and set up using custom software.

Contact

If you have any corrections or suggestions, please e-mail Lasse Deleuran at lassedeleuran@gmail.com.
