FAW Jiefang 6x4 (Discontinued)

Model picture

Go to building instructions.

Building instructions

View the full parts list with links to BrickLink making it easy to find retailers selling the parts you need.

Parts list


This model is controlled using LEGO Power Functions.

Difficulty: Medium.

Number of elements: 653.

#pcs

653

Created August 26, 2011.

Aug

26

2011

Go to this model which has replaced 'FAW Jiefang 6x4' and offers a number of improvements in reliability, stability and playability.

This model is replaced by

Scale: 1:25, Model Team.

Scale

1:25

"Number of wheel sets" x "Driven wheels": 6x4.

Type of Power Functions motor for drive: XL.

Gearing from motor to wheels: 5:9.

Differential type: Stiff.

Drive

6x4

Type of steering geometry: Linear.

Type of Power Functions motor used for steering: M.

Steering

Linear

This model has 2 opening doors

Doors

x2

Created by Lasse Deleuran.

Create a BrickLink Parts list (XML format) for import into BrickLink wanted lists.

Go to the YouTube video for this model.

Go to the Brickshelf folder with this model.

Click to download .mpd file to be open with LDraw tools such as MLCad and LDView.

Print building instructions.

About this model

Although designed to be robust, the combined liftarm and old style technic construction of this truck causes the frame to be rather fragile. This is one of the reasons why this model has been discontinued and replaced by the vastly superior model.

Other reasons include a poorly attached rear bumper, the saddle of the coupling being too tall to work properly and rear wheels with poor grip.



The Power Functions components of this truck are connected as follows


Remote controls

We recommend using the Power Functions remote for controlling this truck.

If the truck is to be driven by people who do not have experience with LEGO Power Functions, then we recommend using our modified remote which blocks the channel selector and uses a long axle as a pointing device.

Building instructions for this LEGO model

The building instructions are made by building the LEGO models in MLCad and generated in LDView using an old version of LPub. All this software is part of LDraw.

Contact

If you have any corrections or suggestions, please e-mail Lasse Deleuran at lassedeleuran@gmail.com.
