FAW Jiefang 6x4

Model picture

Building instructions

Parts list


This model is controlled using LEGO Power Functions.

Difficulty: Easy.

Number of elements: 715.

#pcs

715

Created March 12, 2012.

Mar

12

2012

Scale: 1:25, Model Team.

Scale

1:25

"Number of wheel sets" x "Driven wheels": 6x4.

Type of Power Functions motor for drive: XL.

Gearing from motor to wheels: 5:7.

Differential type: Standard.

Drive

6x4

Type of steering geometry: Linear.

Type of Power Functions motor used for steering: M.

Steering

Linear

This model has 2 opening doors

Doors

x2

Created by Lasse Deleuran.

Go to the YouTube video for this model.

View instructions on BrickHub.org

Go to the Brickshelf folder with this model.

Click to download .mpd file to be opened with LDraw tools such as MLCad and LDView.

Discontinued model due to 'FAW Jiefang 6x4'.

This model replaces

About this model

This Chinese FAW Jiefang 6x4 is designed as a model which is easy to build, repair and drive.

Note that the fuel tanks and the rear wheel shields are the first to break off when driven rough. The rear wheel pair might also eventually fall off as seen in the end of the video.

Children have no problem controlling this truck once they learn to work with the non-self-centering steering. Adults on the other hand... well, see the video.



The Power Functions components of this truck are connected as follows


Remote controls

We recommend using the Power Functions remote for controlling this truck.

If the truck is to be driven by people who do not have experience with LEGO Power Functions, then we recommend using our modified remote which blocks the channel selector and uses a long axle as a pointing device.

How to build your own model

You can build your own copy once you have all the parts in the parts list.

Building instructions for this LEGO model

The building instructions are made by building the LEGO models in MLCad. They are generated in your browser using buildinginstructions.js.
